Angle Seat Piston Valve DN10~DN50 Stainless Steel Body With Plastic Actuator

Angle Seat Piston Valve DN10~DN50 Stainless Steel Body With Plastic Actuator

Angle Seat Piston Valve DN10~DN50 Stainless Steel Body With Plastic Actuator

Product Details:

Place of Origin: Ningbo China(Mainland)
Brand Name: FLUIDAC or OEM
Certification: ISO9001
Model Number: PVA-15-2-S-NC

Payment & Shipping Terms:

Minimum Order Quantity: 5 piece
Price: USD20--
Packaging Details: Boxes, Cartons,Wooden cases,Pallets
Delivery Time: Within 20 days after receiving payment or deposit
Payment Terms: TT Advance/30% deposit,70% by copy Bill oflading,Western Union,MoneyGram,Paypal
Supply Ability: 10000 Pieces Per month
Contact Now
Detailed Product Description
Conttoling Pressure: 0.3mpa-0.8mpa Series: PVA Series
Working Pressure: 0-1.6MPa Body Material: Aluminum
Product Name: Solenoid Valve Type: Two Position Two Way
Working Medium: Water|Gas





Angle Seat Piston Valve DN10~DN50 Stainless Steel Body With Plastic Actuator

PVA Series angle seat piston valve with plastic actuator two position two way single acting or double acting DN10~DN50 for liquids and gases with external pilot-operated and 360°turnable actuator





Quick Detail:



* PVA Series Angle seat piston valve Equivalent

* Two position two way,External pilot-operated

* DN10mm,DN15mm,DN20mm,DN32mm,DN40mm,DN50mm

* Body Material stainless steel 304 or Stainless steel 316

* Actuator material Engneering plastic

* Easy for mounting,actuator can be 360°turnable

* Downstream installing and Upstream installing both available

* Fast respond,low noise,low consumption

* Stable design,External pilot-operated for long serive life and no need for maintenance





Applications:





PAV Series angle seat piston valve external pilot-operated,with Y shape angle type design big flow and long service life.

PAV series angle seat valve used widely used to control work medium flow rate,it can be apply to high temperature and strong corrosion environment.

PAV series valve widely used in the Environment protection,textile,medical equipment,food industrial etc



Specifications:



ORDERING CODE

PVA

15

1

S

Type

DN  and Port Size

Body Material Code

Motion Pattern And Mounting

PVA:PVA Series Angle seat piston valve with Engineering Plastic actuator

10:G3/8"

1:Brass

S: Single Acting

15:G1/2"

20:G3/4"

25:G1"

2:Stainless Steel 304

D: Double Acting

32:G1-1/4"

40:G1-1/2"

3:Stainless Steel 316L

F:Flange Mounting



SPECIFICATION

Body material: S.S316/S.S304/Brass
Aclualor material: engineering plastic
Disk seal: PTFE/FPM
Stem seal: PTFE/FPM
Piston seal: FPM/NBR
Technical parameter
Connection size: DN10-DN50
Thread: 3/8"-2"
Applicable medium: water, neutral gas or liquid, allohol, oil,organic.

Temperature of medium:
PTFE: -10℃- +180℃
FPM: -10℃- +100℃
Viscidity: max600 mm2/s
Downstream installing/Upstream installing
Conttoling medium: air/neutral gas
Conttoling pressure: 0.3-O.8MPa
Working pressure: 0-1.6MPa



Angle Seat Piston Valve DN10~DN50 Stainless Steel Body With Plastic Actuator

DN

G

L

L1

SW

H

D

Actuator

10

3/8"

55

17

21

170

54

50

15

1/2"

70

21

26.5

185

63

50

20

3/4"

76

23

32

190

63

50

25

1"

90

25

40

200

63

50

32

1-1/4"

116

32

50

240

81

63

40

1-1/2"

116

32

55.5

280

96

80

50

2"

138

40

68.5

295

96

80



1.1 body

3.1 screw connector

5.5 lock nul

1.2 cylinder

3.2 V seeling

5.6 piston

1.3 cylinder covet

3.3 seal ring

5.7 seal ring

1.4 observation window

3.4 gasket

5.8 gasket

2.1 bolt

3.5 spring

5.9 hexagon nut

2.2 orifice plate seal

4.1 connecling nul

5.10 spring

2.3 seal disk

4.2 seal ring

5.11 position indicator

2A disk

4.3 lock nut



2.5 stem

4.4 leaf spring
